Aluminium Punching and Cutting Machine
Special Purpose Machines (SPM'S)The Aluminium Punching and Cutting Machine by TL Pathak Group is a high-performance industrial tool designed for precision processing of aluminum materials. This machine integrates both punching and cutting operations, ensuring efficiency and accuracy in metal fabrication tasks. With a robust design, it offers high stability and minimal vibration, resulting in clean cuts and smooth edges. The machine is equipped with advanced automation features, allowing for programmable settings that can accommodate various shapes and sizes of aluminum sheets or profiles. Its user-friendly interface simplifies operation, reducing manual effort and increasing productivity. Ideal for applications in construction, automotive, and aerospace industries, the TL Pathak machine ensures optimal speed and precision. Its durability, combined with low maintenance requirements, makes it a reliable choice for heavy-duty industrial use, enhancing production efficiency and reducing material waste.
Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Model | TLPAPCM |
| Max. Pipe Length | 3000 mm (upto 12 mtr. on request) |
| Max. Punching Speed | 5 Seconds/Hole (will varry according to the profile) |
| Max. Pipe Size | 80x80 and 5 mm Thickness MS (can be Modified according to requirement) |
| Material and Shape | MS, SS, Aluminium, Copper (Square, Rectangle, Oblong, Round and Oval) |
| Press Height Control | Automatic With Proximity Switches (Auto Height Control) |
| Accuracy | Linear Positioning Accuracy +- <0.5 mm Linear Repeat Precision +- 0.25 mm |
| Machine Bed Structure | Material (MS HR), Metal Weight (950 kgs/Mtr.), Fabricated from 100x50x5 mm Box Structure (Stress Relieved and Machined) |
| Power Requirement for CNC Machine | 220 V 2.5 K.W. (Single Phase) |
| Power Requirement for Hydraulic Machine | 415 V (3 Phase) 7.5 H.P.(depends on model) |
| Material Clamping | Pneumatic Toggle Clamp -500 Kgs (Adjustable) |
| Electric Components | Schindler and Siemens Brand CAM Software : Inbuild in PLC (PC Software) |
