CNC Pvc Pipe Threading Lathe Machine
Lathe MachinesA CNC PVC Pipe Threading Lathe Machine is a computer-controlled lathe specially designed for precision threading of PVC (Polyvinyl Chloride) pipes used in plumbing, irrigation, and electrical conduit systems. Unlike traditional metal-threading lathes, this machine is optimized for non-metallic materials, offering high speed, minimal tool wear, and clean thread finishes.
From ₹
1,250,000
To
2,080,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-8035735963 OR Call Me Back
| Parameter | Specification |
| Pipe Diameter Range | 20 mm – 315 mm (customizable) |
| Max Pipe Length | 500 mm – 6000 mm |
| Spindle Bore | 80 mm – 300 mm |
| Thread Types Supported | BSPT, NPT, BSP, ISO, DIN |
| Spindle Speed | 100 – 1200 RPM |
| No. of Axes | 2 to 4 (X & Z standard) |
| Control System | CNC (Siemens/Fanuc/Delta) |
| Positioning Accuracy | ±0.02 mm |
| Motor Power | 3 – 10 HP |
| Frame Construction | Cast Iron/Steel Base Frame |
We are one of the leading engineering and manufacturing companies that offer CNC PVC pipe threading lathe machines at the cheapest rate. We offer a high-quality and reliable machine that has first-class machine parts and over a large year of engineering know-how. You can also ask our engineers to customize this machine as per your needs and they will do so.
Key Features
| CNC Controller (Fanuc / Siemens / Delta) for programmable operation |
| High-Speed Spindle optimized for PVC material |
| Special Carbide or Diamond-Coated Tools for plastic threading |
| Tailstock & Pipe Holding Fixtures for long and hollow pipe support |
| Automatic Pipe Loading (optional) |
| Chip Extraction System to remove plastic shavings |
| Servo-Driven Axis for high-precision threading cycles |
| Cooling/Air Blowing System (dry cutting or minimal lubrication) |
3D angled front view with all parts labeled for CNC Pvc Pipe Threading Lathe Machine
Applications of CNC Pvc Pipe Threading Lathe Machine
| PVC pipe manufacturing plants |
| Plumbing and irrigation pipe production |
| Electrical conduit pipe threading |
| Agriculture water pipe threading |
| Chemical and drainage piping systems |
| Borewell and casing pipe manufacturers |
| Infrastructure and construction material suppliers |
Uses of CNC Pvc Pipe Threading Lathe Machine
| Precision external threading on PVC pipes |
| Custom thread profiles for different coupling types |
| Batch production of threaded pipe ends |
| Ensures consistent thread depth and pitch |
| Automated, high-speed threading process |
| Reduces labor cost and manual errors |
| Compatible with different pipe diameters and lengths |
