Mini Hydraulic Press Brake Machine
Sheet Metal MachinesWe are providing a broad array of our mini hydraulic press brake machines as the heavy-duty steel construction frame of our machine absorbs the heavy shocks of overload. We have machined all the welding edges properly to weld the joints. This mini machine works with less power consumption and gives fast production on smaller jobs. This machine is very cost-effective.
From ₹
525,000
To
585,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me BackModel | Tonage | Bending (Vap. M.M.(M.S) | Table Width | Clear Distance | Ram Stoke | Open Height | Depth | Power H.P | Speed App. Pre Ret. | Packing Dimension M.M. (LXWXH) |
PHPB-212 | 20 | 1270x2 | 125 | 900 | 100 | 250 | 200 | 3 | 35-9-60 | 1400x1050x1900 |
PHPB-320 | 30 | 2030x2 | 125 | l500 | 100 | 250 | 3 | 30-9-53 | 2200x1050x1900 | |
PHPB-425 | 40 | 2540x2 | l50 | 2000 | 100 | 250 | 200 | 5 | 35-9-55 | 2200x1050x1900 |
PHPB-530 | 50 | 3125x2 | 175 | 2500 | 125 | 250 | 200 | 5 | 30-7-55 | 3300x1050x1900 |
PHPB-612 | 60 | 1270x4 | 175 | 900 | 125 | 330 | 200 | 5 | 25-6-50 | 1400x1200x2000 |
PHPB-620 | 60 | 2030x4 | 175 | l550 | 125 | 330 | 200 | 5 | 26-6-50 | 2200x1200x2000 |
PHPB-825 | 80 | 2540x4 | 200 | 2000 | l50 | 330 | 250 | 7.5 | 37-6-41 | 2700x1500x2200 |
PHPB-1025 | 100 | 2540x6 | 200 | 2000 | l50 | 330 | 250 | 7.5 | 40-5-40 | 2700x1600x2300 |
PHPB-1030 | 100 | 3125x4 | 200 | 2500 | l50 | 330 | 250 | 7.5 | 40-5-40 | 3300x1600x2300 |
PHPB-1060 | 100 | 6000x2 | 200 | 5000 | l50 | 330 | 300 | 7.5 | 40-6-40 | 6200x1600x2300 |
PHPB-1225 | 120 | 2540x6 | 125 | 2000 | l50 | 330 | 300 | 10 | 41-6-41 | 2700x1700x2500 |
PHPB-1625 | 160 | 2540x8 | 125 | 2000 | 200 | 375 | 300 | l5 | 40-6-40 | 2700x1800x2500 |
PHPB-1630 | 160 | 3125x6 | 125 | 2500 | 200 | 375 | 300 | l5 | 40-6-40 | 3300x1800x2500 |
PHPB-2025 | 200 | 2540x10 | 250 | 2000 | 200 | 375 | 300 | 20 | 37-5-37 | 2700x2000x2600 |
PHPB-2030 | 200 | 3125x8 | 250 | 2500 | 200 | 375 | 300 | 20 | 37-5-37 | 3300x2000x2600 |
PHPB-2040 | 200 | 4000x6 | 250 | 3000 | 200 | 375 | 300 | 20 | 37-5-37 | 4200x2000x2600 |
PHPB-2060 | 200 | 6000x4 | 250 | 5000 | 200 | 375 | 300 | 20 | 37-5-37 | 6200x2000x2600 |
PHPB- 2530 | 250 | 3125x10 | 250 | 2500 | 200 | 375 | 300 | 25 | 40-5-40 | 3300x2100x2700 |
PHPB-2540 | 250 | 4000x8 | 250 | 3000 | 200 | 375 | 300 | 25 | 40-5-40 | 4200x2100x2700 |
PHPB-2550 | 250 | 5000x6 | 250 | 4000 | 200 | 375 | 300 | 25 | 40-5-40 | 5200x2100x2700 |
PHPB-3025 | 300 | 2540x16 | 275 | 2000 | 200 | 425 | 300 | 30 | 36-5-36 | 2700x2150x2900 |
PHPB-3040 | 300 | 4000Xl0 | 275 | 3000 | 200 | 425 | 300 | 30 | 36-5-36 | 4200x2150x2900 |
PHPB-3060 | 300 | 6000x6 | 275 | 5000 | 250 | 425 | 300 | 30 | 36-5-36 | 6200x2150x2900 |
PHPB-4025 | 400 | 2540 x20 | 300 | 2000 | 250 | 425 | 350 | 40 | 34-5-34 | 2700x2200x3000 |
PHPB-4030 | 400 | 3125x16 | 300 | 2500 | 250 | 450 | 350 | 40 | 34-5-34 | 3300x2200x3000 |
PHPB-5030 | 500 | 3125x20 | 350 | 2500 | 250 | 450 | 400 | 50 | 28-5-28 | 3300x2300x3200 |
PHPB-5040 | 500 | 4000x16 | 350 | 3000 | 250 | 450 | 400 | 50 | 28-5-28 | 4200x2300x3200 |
PHPB-5060 | 500 | 6000x10 | 350 | 5000 | 250 | 450 | 400 | 50 | 28-5-28 | 6200x2300x3200 |
