C Frame Open Throat Hydraulic Press 30 Ton
Press MachinesPathak Offering best quality C Frame Open Throat Hydraulic press 30 Ton with various standard accessories, such as advanced 2-speed control, the fully adjustable stroke made with premium quality material, and cold steel welded construction. The machine is used to perform various functions smoothly and is made with the latest technology under the guidance of our highly qualified engineers team.
From ₹
325,000
To
645,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| MODEL | OTP1 | OTP2 | OTP3 | OTP5 | OTP7 | OTP10 | OTP15 | |
| SPECIFICATIONS | 10 Tons | 20 Tons | 30 Tons | 50 Tons | 75 Tons< | 100 Tons | 150 Tons | |
| Dia of crank shaft | mm | 80 | 90 | 100 | 115 | 125< | 150 | 175 |
| Adjustability of stroke | mm | 50 | 76 | 76 | 100 | 100< | 125 | 150 |
| Punch Bore in Ram | mm | 25 | 31 | 31 | 38 | 38< | 45 | 50 |
| Width of Bed | mm | 300 | 375 | 440 | 525 | 600< | 650 | 700 |
| Length of Bed | mm | 450 | 550 | 615 | 700 | 800< | 900 | 1000 |
| Gear Dia | mm | 450 | 525 | 600 | 650 | 890< | 960 | 1060 |
| Fly Wheel Dia | mm | 525 | 650 | 700 | 800 | 900< | 1000 | 1125 |
| Gap (Bed to Bottom) | mm | 250 | 325 | 350 | 375 | 400< | 450 | 500 |
| Stroke Per Minute | mm | 60 | 55 | 50 | 45 | 40< | 40 | 35 |
| H.P. Required (1440) | mm | 2 | 3 | 3 | 5 | 7.5< | 10 | 15 |
| Bore in Bed | mm | 110 | 125 | 140 | 160 | 190< | 220 | 250 |
| Weight in kgs (Approx) | mm | 900 | 1550 | 2050 | 2700 | 4000< | 5500 | 7800 |
