Other MachinesWe are well-known for our premium quality work in electrical discharge machines as we use the latest technology to produce our products. This machine is manufactured with an electrothermal process where a single strand of metal wire allows the wire to cut through metal with the help of heat from electrical sparks. You can buy our machines at low prices also as we manufacture machines keeping in mind the needs of customers.
From ₹
845,000
To
1,148,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me BackModel | Unit | PEWC H25 | PEWC H35 | PEWC H40 | PEWC H45 | PEWC H40J | PEWC H50 | PEWC H50J | PEWC H63 |
Working Table Size X-Y | mm | 580x400 | 580x400 | 580x400 | 580x400 | 580x400 | 580x400 | 580x400 | 580x400 |
Tabel Travel | mm | 320x250 | 320x250 | 320x250 | 320x250 | 320x250 | 320x250 | 320x250 | 320x250 |
Max. Z Axis Travel | mm | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
Max. Work Piece Weight | kg | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 |
Max. Cutting angle | o | 3* | 3* | 3* | 3* | 3* | 3* | 3* | 3* |
Cutting Speed | mm2/min | Standard : 90, High Speed : 140 | |||||||
Position Accuracy | mm | 0.015/300 | |||||||
Repeatability | mm | 0.01 | |||||||
Wire Moving Speed | m/s | 11.5 | |||||||
Net Weight | kg | 900 | 1200 | 1350 | 1350 | 1400 | 2100 | 2300 | 300 |
Power | kw | 3 Phase 400 VAC / 50 Hz (Less than 1Kw) |
