Surface Grinder For Refractories

Grinding Machines
TL Pathak Group in India offers specialized Surface Grinders designed specifically for refractories. These machines are engineered to meet the unique challenges of grinding refractory materials effectively. Refractories are known for their high hardness and resistance, requiring specialized grinding techniques.TL Pathak Group's Surface Grinders for refractories feature robust construction and powerful grinding capabilities to handle these tough materials. They are equipped with advanced grinding wheels and precision mechanisms to ensure accurate and efficient grinding operations. The machines are designed to withstand the abrasive nature of refractories and deliver consistent results. TL Pathak Group's Surface Grinders for refractories are built with the highest quality standards, providing reliability and durability for long-term use in refractory applications.
From ₹
125,000 To 150,000

Download Catalog Request Catalog

Order By Phone

Shipping Information Usually dispatched With In business days

+91-9124009247 OR Call Me Back
Models PPSC-20 PPSC-24 PPSC-30
Working Surface of Table 525X205 MM 625X200 MM 625x300 MM
Grinding Capacity 500X200 MM 600X200 MM 600X300 MM
Longitudinal Traverse 525 MM 610 MM 630 MM
Cross Traverse 215 MM 215 MM 320 MM
Vertical Traverse 250 MM 250 MM 330 MM
Grinding Wheel Dia and Width 200X12 MM 200X12 MM 200X12 MM
Spindle Speed 2800 RPM 2800 RPM 2800 RPM
Cross Feed Graduation .05 MM .05 MM .05 MM
Vertical Feed Graduation .02 MM .02 MM .02 MM
Floor Space Requires 1150X900 MM 1250X1200 MM 1850X1350 MM
Weight Gross 1250X kgs. Approx 1350 kgs. Approx 1750 kgs. Approx
ELECTRICALS
-
-
-
Electrical Motors For Grinding Wheel 1.0 H.P 2800 1.0 H.P 2800
-
Elecrtrical Motor For Auto Feed Models Only
-
1.0 H.P 1440
-
