Cnc and Nc Surface Grinder
Grinding MachinesTL Pathak Group in India offers CNC (Computer Numerical Control) and NC (Numerical Control) surface grinders. These precision grinding machines are designed for achieving exceptional surface finishes and tight tolerances. CNC surface grinders utilize advanced computer technology to automate the grinding process, resulting in precise and consistent results. They offer enhanced flexibility and efficiency, allowing for complex grinding operations with ease. On the other hand, NC surface grinders feature numerical control systems that enable accurate positioning and movement of the grinding wheel, enhancing productivity and accuracy. TL Pathak Group's CNC and NC surface grinders are reliable and versatile tools for various industries, providing high-quality surface grinding solutions.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me BackModels | PPSC-20 | PPSC-24 | PPSC-30 |
Working Surface of Table | 525X205 MM | 625X200 MM | 625x300 MM |
Grinding Capacity | 500X200 MM | 600X200 MM | 600X300 MM |
Longitudinal Traverse | 525 MM | 610 MM | 630 MM |
Cross Traverse | 215 MM | 215 MM | 320 MM |
Vertical Traverse | 250 MM | 250 MM | 330 MM |
Grinding Wheel Dia and Width | 200X12 MM | 200X12 MM | 200X12 MM |
Spindle Speed | 2800 RPM | 2800 RPM | 2800 RPM |
Cross Feed Graduation | .05 MM | .05 MM | .05 MM |
Vertical Feed Graduation | .02 MM | .02 MM | .02 MM |
Floor Space Requires | 1150X900 MM | 1250X1200 MM | 1850X1350 MM |
Weight Gross | 1250X kgs. Approx | 1350 kgs. Approx | 1750 kgs. Approx |
ELECTRICALS |
- |
- |
- |
Electrical Motors For Grinding Wheel | 1.0 H.P 2800 | 1.0 H.P 2800 | - |
Elecrtrical Motor For Auto Feed Models Only | - |
1.0 H.P 1440 | - |
