Power Operated Hydraulic Press Machine 10-Ton
Press MachinesOur team manufactures the best quality Power-operated hydraulic press machine 10-ton with an oversized pump and hand-operated controlled valve. You can adjust the pressure mainly used in forging, clinching, moulding, blanking, punching, deep drawing, and metal forming operations. Our skilful team made this machine with the latest technology.
From ₹
90,000
To
110,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
Variable Stroke Adjustment With Limit Switch
Pressure reversal hydraulic switches
Front Operator Control Box
Stroke Counter
| Tons | Between column Length x Width mm.mm. | Between Ram to Bed Min.Max. mm.mm. | Travel of Ram mm. | Motor Power H.P. |
| 15 | 650X150 | 75X600 | 150 | 3 |
| 20 | 700X225 | 150X750 | 150 | 3 |
| 25 | 850X300 | 180X910 | 180 | 5 |
| 40 | 950X350 | 180X910 | 190 | 5 |
| 50 | 1000X400 | 180X950 | 200 | 5 |
| 60 | 1050X450 | 180X975 | 200 | 5 |
| 75 | 1150X500 | 180X975 | 210 | 7.5 |
| 100 | 1200X600 | 180X975 | 225 | 7.5 |
| 150 | 1300X635 | 180X975 | 240 | 10 |
| 200 | 1325X650 | 180X975 | 240 | 10 |
| 250 | 1350X650 | 180X975 | 250 | 20 |
| 300 | 1395X660 | 180X975 | 265 | 20 |
| 500 | 1425X685 | 180X975 | 300 | 25 |
