Horizontal Double Column Bandsaw Machine Model-175 S
Cutting MachinesThe horizontal bandsaw 175 S is a powerful cutting machine designed for precise and efficient cutting of various materials, including metal, wood, plastics, and more. Manufactured by TL Pathak Group in India, this machine features a sturdy construction and a high-quality blade that enables it to cut through tough materials with ease.
The bandsaw 175 S offers a cutting capacity of up to 175mm, making it suitable for a wide range of cutting applications in industrial settings. Its advanced control system allows for easy adjustment of cutting speed and blade tension, ensuring precise and accurate cuts every time.
With its user-friendly design and advanced features, the horizontal bandsaw 175 S is an ideal choice for metalworking shops, woodworking shops, and other industrial applications that require fast and efficient cutting of materials. TL Pathak Group is committed to providing high-quality cutting solutions to its customers, and the bandsaw 175 S is a testament to this commitment.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Model | 175 S | 175 S.A. | 175 H.L.C. |
| Cutting Capacity Round Bar(mm) | 175 | 175 | 175 |
| Square(mm) | 160x160 | 160x160 | 160x160 |
| Blade Size(mm) | 27x0.9x2515 | 27x0.9x2515 | 27x0.9x2515 |
| Motor power | 1 H.P./1440 RPM | 1 H.P./1440 RPM | 1 H.P./1440 RPM |
| Coolant Pump Power | 0.15 H.P./2800 RPM | 0.15 H.P./2800 RPM | 0.15 H.P./2800 RPM |
| Hydraulic Drive Motor | x | 0.25 H.P./1500 RPM | 0.25 H.P./1500 RPM |
| Cutting Speed Control | Power Hydraulic | Power Hydraulic | Power Hydraulic |
| Blade Speed Min/Mtr | 32/42 | 32/42 | 32/42 |
| Net Weight | 210 kg | 210 kg | 210 kg |
| Overall Dimension | 1150x500x1400(LxWxH) | 1150x500x1400(LxWxH) | 1150x500x1400(LxWxH) |
