Semi Gear Head Lathe Machine
Lathe MachinesThe Semi Gear Head Lathe Machine by TL Pathak Group is a versatile and high-performance tool designed to meet the demands of precision metal turning. This lathe machine boasts a semi gear head design, combining the benefits of both gear head and cone pulley systems. It offers enhanced flexibility and ease of use, making it suitable for a wide range of turning applications in diverse industries,equipped with a powerful motor, the Semi Gear Head Lathe Machine ensures efficient and accurate machining. The gear head design allows for variable speed control, enabling operators to choose the optimal speed for different materials and machining tasks. This versatility makes it an ideal choice for turning various workpieces with different hardness levels.
The machine features a robust and rigid structure that enhances stability during operation, minimizing vibrations and ensuring precision in the turned components. The bed and other components are meticulously crafted to withstand heavy-duty usage and provide long-lasting reliability,user-friendly controls and an ergonomic design contribute to an efficient and comfortable working experience. TL Pathak Group's commitment to quality and innovation is evident in the Semi Gear Head Lathe Machine, reflecting their dedication to providing manufacturers with state-of-the-art machinery that meets the evolving needs of modern metalworking processes. Whether in small-scale workshops or large-scale production facilities, this lathe machine stands as a reliable and efficient solution for achieving high-precision turning results.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me BackMODEL | TLPSGL-614 | TLPSGL-814 | TLPSGL-817 | TLPSGL-1017 | TLPSGL-1217 | TLPSGL-1617 |
Bed Length | 6 feet | 8 feet | 8 feet | 10 feet | 12 feet | 12 feet |
Width of Bed | 350 mm | 350 mm | 425 mm | 425 mm | 425 mm | 425 mm |
Height of Center | 300 mm | 300 mm | 375 mm | 375 mm | 375 mm | 375 mm |
Swing Over Bed | 600 mm | 600 mm | 750 mm | 750 mm | 750 mm | 750 mm |
Spindle Bore | 75 mm | 75 mm | 80 or 120 mm | 80 or 120 mm | 80 or 120 mm | 80 or 120 mm |
Admit Between Center | 1000 mm | 1500 mm | 1350 mm | 1850 mm | 2400 mm | 3500 mm |
Spindle Speed | 3+3=6 | 3+3=6 | 3+3=6 | 3+3=6 | 3+3=6 | 3+3=6 |
