Mechanical Pneumatic Press Brake Machine
Sheet Metal MachinesWe are one of the most reputed manufacturers and exporters of mechanical pneumatic press brake machines in the market. These machines are manufactured with the use of technically advanced equipment under the guidance of our experts. The heavy-duty frame of our machines is of robust steel construction of the rigid and interlocked design. Our machines are widely demanded by many customers as these are available in diverse specifications.
From ₹
485,000
To
545,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me BackFoot pedal and die block lifting ling.
Fly wheel and gear guard
Self lubrication system
Motor pulley stroke counter
Motor mounting bracket
Standard V Block & Punch
Motor mounting bracket
Motorize back gauge
Self lubrication
Motor pulley
V belts
Model | Tone | Bending Cap in MS Length-X Thickness | Clearance Between Hostings | Stroke Per Minute | Stroke of Ram M.M | Ram Agj. M.M | Shut Height Ram Stroke | Depth of Throat M.M | Main Motor H.P/KW | Ram adj. Ele. Motor H.P/KW | Overall Dimension in M.M | ||
Length | Width | Height | |||||||||||
PPB-1 | 20 | 1525X1.6 | 1000 | 35 | 50 | 40 | 175 | 200 | 3/2.2 | 0.5/0.37 | 2000 | 1125 | 2300 |
PPB-2 | 25 | 2000X1.6 | 1220 | 35 | 50 | 40 | 200 | 200 | 5/3.7 | 0.5/0.37 | 2300 | 1200 | 2500 |
PPB-3 | 40 | 2500X2 | 1550 | 35 | 60 | 50 | 215 | 250 | 7.5/5.6 | 1/0.75 | 2800 | 1500 | 2650 |
PPB-4 | 65 | 3125.X2.5 | 1900 | 30 | 76 | 50 | 275 | 300 | 10/7.6 | 1.5/1.1 | 3400 | 1575 | 2750 |
PPB-5 | 65 | 2000X4 | 1370 | 30 | 76 | 63 | 275 | 300 | 10/7.6 | 1.5/1.1 | 2400 | 1575 | 2750 |
PPB-6 | 80 | 2500X4 | 1550 | 25 | 76 | 63 | 300 | 300 | 12.5/9.7 | 2/1.5 | 2900 | 1650 | 3025 |
PPB-7 | 100 | 3125X4 | 1900 | 25 | 76 | 80 | 300 | 300 | 15/11.2 | 2/1.5 | 3450 | 1875 | 3525 |
PPB-8 | 120 | 2500X6 | 1700 | 25 | 76 | 80 | 300 | 300 | 20/15 | 2/1.5 | 2900 | 1900 | 3550 |
PPB-9 | 150 | 2500X8 | 1700 | 20 | 80 | 100 | 300 | 300 | 25/18.8 | 2/1.5 | 3400 | 1900 | 3550 |
PPB-10 | 150 | 3125X6 | 1900 | 20 | 80 | 100 | 300 | 300 | 25/18.7 | 2/1.5 | 3400 | 1950 |
Electric Pannels
Roofings
Bus Bodies
Kitchen Equipments
Generator Enclosure
Steel Tanks
Stainless Steel Equipment
Coil Cutting Industries
Air Condition Ducts
Container Manufacturing
Flour Making Machines
Industrial Structure
Rail Coaches
Tipper Trucks
Wind Mill Manufacturing
Turnine Enclosures
