Panel Processing Machines
Wood Working MachinesPathak manufacturing best quality panel processing machine with double glue spread, heat bonding and pneumatic edge-cutting and its design allows to trim and buff both upper and lower edges on straight panels. The machine provides higher output with the help of the latest technology used in manufacturing and becomes straightforward to use.
From ₹
450,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me BackDESCRIPTION | PHP-100 | PHP-150 |
Workable Table Size | 1300x2500x42mm | 1500x3100x42mm |
Max Pressure of workable | 100T | 150T |
Pressure of Hydraulic system | 210kgs/cm2 | 240kgs/cm2 |
Max.Platen Opening | 300mm | 300mm |
Oil Cycling Dia | 100mm x 6pcs | 100mm x 8pcs |
Hydraulic Pump Power | 5.5KW | 2.2KW |
Heating pipe power | 1x18KW | 2x18KW |
