Hand Spot Welding
Welding EquipmentsThe Hand Spot welding machine has been made following one of the recent technologies in the welding field. Many types of supplementary functions clarify the work of the welder and it helps in increasing the productivity of the person who is working with it. It is satisfying because the job demands an uninterrupted change of the welding methods. Pathak welding equipment's manufacturer machines come with multi-system welding units which have the three most usual welding methods of a similar package.
From ₹
58,000
To
125,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Model | PHSW-16 |
| Output KVA | 16 |
| Input primary voltage (AC) | 415V (2-Phase) |
| Rated frequency (HZS) | 50/60 |
| No-load voltage (Max OCV) (Volt) | 9 |
| Primary line current (Max (AMP) | 55 |
| Dimension (approx) (H*L*W) (MM) | 625+510+800 |
| Weight (without gun and cable) (approx kg) | 104 |
| Gun & cable weight (approx Kg) | 9.5 |
| Output work cable with water cooling length (Mtr) | 3 |
| Earth cable with water cable length (Mtr) | 3 |
| Cooling | Natural |
| Insulation Class | A |
| Time control (KA) | Solid stage electronic |
| Output current selection (way) | 8 Step |
| Time control (step) | Cycle / second |
