Gondola Shelving Punching Machine
Special Purpose Machines (SPM'S)The TL Pathak Group's Gondola Shelving Punching Machine is a precision-engineered tool designed to streamline the production process of gondola shelving units. This innovative machine is equipped with cutting-edge technology to efficiently punch holes and slots into shelving components, ensuring accuracy and consistency in the manufacturing process. With its automated operation and customizable features, including adjustable punching parameters and tooling options, it offers versatility to accommodate various shelving designs and specifications. The machine's robust construction and advanced controls ensure reliable performance and long-term durability, contributing to increased productivity and cost-effectiveness for manufacturers. Whether for retail displays, storage solutions, or commercial applications, the Gondola Shelving Punching Machine from the TL Pathak Group stands as a reliable solution, meeting the demands of modern manufacturing environments with precision and efficiency.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Model Name | TLPGSP |
| Body | Mild Steel Fabricated with 8 mm and 20 mm plate |
| Body Head | 50 mm plates |
| Accuracy | +-0.10 mm |
| Sensor | Yes |
| Oil Pump | Hydraulic Pump |
| Electric Motor | 7.5 H.P. Crompton Make |
| Lubrication | Auto Lubrication |
| Maximum Tube Length | 3000 mm (3 m.) |
| Punching Capacity | 5x85 mm |
| Hydraulic Tank | 150 lit. (Without Oil) |
| Electric Panel | 1 Nos. |
| Cycle Time | 3 sec per hole including feed |
| Pipe Clamping | By Hydraulic Cylinder |
| Gear Box | Planetory Gear Box (Delta) |
| HMI | Fuji |
